Designed as a two over five shed SSB triple layer fabric, the PRINT SSB60205YF68-400CFM features a 2 to 1 CD yarn ratio that optimizes the balance between support and drainage. The very fine plain weave paper side provides maximized fiber support for good retention and very high sheet support. High open area enables excellent drainage capacity, allowing rapid water removal without compromising formation quality. The fabric delivers formation improvements and good printability for superior end-product appearance. Medium diameter yarns contribute to good wear potential, while high MD and CD stiffness ensure dimensional stability under dynamic machine conditions.

Key Features

Two-shed paper side with paired CD binding yarns
Independent layers securely bound together
Very fine plain weave top surface

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF68
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.

Umbauten:

mit einer Breite von nicht mehr als 30 mm

temperature resistant paper machine fabric

Temperaturbeständiges Papiermaschinengewebe

Verwandte Produkte

SSB Triple Layer Paper Machine Cloth with 3 to 2 CD Yarn Ratio and Long Float Wear Side for Excellent Wear Potential and Dimensional Stability

Beste Preis erhalten

SSB Triple Layer Forming Fabric with Plain Weave Top and Eight Shed Wear Side Featuring Low Wire Mark and Excellent Retention for Quality Papers

Beste Preis erhalten

SSB Triple Layer Paper Making Forming Fabric with Plain Weave Paper Side and Eight Shed Wear Side Offering High Sheet Support and Drainage

Beste Preis erhalten

Triple Layer Forming Fabric with High MD and CD Stiffness for Dimensional Stability and Medium Yarn Wear Resistance Featuring SSB Weave Design

Beste Preis erhalten

SSB Triple Layer Paper Making Forming Fabric PRINT SSB60205YM61 with Two over Five Shed Shute Binding for Very High Sheet Support

Beste Preis erhalten

Einzelheiten Zu Den Produkten

Zu Hause > Produits >

Formgewebe

SSB Forming Fabric High Drainage Featuring Very Fine Plain Weave Top Surface with Maximized Fiber Support and Excellent Formation for Printing Papers

Alle Kategorien

SSB Forming Fabric High Drainage Featuring Very Fine Plain Weave Top Surface with Maximized Fiber Support and Excellent Formation for Printing Papers

Markenbezeichnung:	ATMC
MOQ:	1 Stk
Preis:	inquiry
Verpackungsdetails:	Standardgehäuse aus Folienholz für die Ausfuhr
Zahlungsbedingungen:	L/C, D/A, D/P, T/T

Ausführliche Information

Beschreibung des Produkts

Ausführliche Information

Markenname:

ATMC

Durchmesser des Gewebes (mm):

Bruchstärke:

Gewicht (GSM):

Musterbeschreibung:

Luftdurchlässigkeit:

Abflussindex (DI):

Warp / Schussmaterial:

Offener Bereich:

Struktur:

Zähler (mm):

Fiber-Support-Index (FSI):

Stofffarbe:

Maschen × Anzahl (l/cm):

Warp-Durchmesser (mm):

Min Bestellmenge:

1 Stk

Preis:

inquiry

Verpackung Informationen:

Standardgehäuse aus Folienholz für die Ausfuhr

Lieferzeit:

5-8 Arbeitswochen

Zahlungsbedingungen:

L/C, D/A, D/P, T/T

Hervorheben:
