The PRINT DAL67816SM is a double layer forming fabric engineered with a fine eight shed paper side weave over a sixteen shed wear side construction. The paper side features extra cross direction support yarns that deliver high fiber retention, while the robust wear side incorporates a pronounced CD crimp with large diameter yarns for extended life potential. This unique combination achieves both high fiber support and very high drainage capacity within a single fabric design. The large diameter CD crimp on the machine side effectively protects MD warp yarns from abrasion and increases wear yarn mass. The robust construction withstands high MD loads and resists CD ridging, making this fabric suitable for printing and writing paper, light weight kraft, and board grades.

Key Features

Eight over sixteen shed double layer weave construction
Fine mesh eight shed paper side with extra CD support yarns
Sixteen shed wear side weave for good service life
High fiber support for excellent retention performance

Product Parameters

Product Name	Forming Fabric PRINT DAL67816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..

Umbauten:

8 Stoffe aus Papierformmaschinen

2.5 Schicht-Polyester-Formgewebe

Gewebe

Verwandte Produkte

Double Layer Forming Wire with Robust Construction and High Fiber Support Offering Very High Drainage and Resistance to CD Ridging

Beste Preis erhalten

Double Layer Paper Making Wire with Enhanced Abrasion Resistance and High MD Load Capacity Featuring 8 over 16 Shed Weave Pattern

Beste Preis erhalten

Paper Machine Double Layer Cloth with 8 Shed Support Side and 16 Shed Wear Side for Good Retention and Long Service Life Potential

Beste Preis erhalten

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

Beste Preis erhalten

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Beste Preis erhalten

Einzelheiten Zu Den Produkten

Zu Hause > Produits >

Formgewebe

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Alle Kategorien

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Markenbezeichnung:	ATMC
MOQ:	1 Stk
Preis:	inquiry
Verpackungsdetails:	Standardgehäuse aus Folienholz für die Ausfuhr
Zahlungsbedingungen:	L/C, D/A, D/P, T/T

Ausführliche Information

Beschreibung des Produkts

Ausführliche Information

Markenname:

ATMC

Struktur:

Musterbeschreibung:

Maschen × Anzahl (l/cm):

Warp-Durchmesser (mm):

Durchmesser des Gewebes (mm):

Warp / Schussmaterial:

Luftdurchlässigkeit:

Zähler (mm):

Bruchstärke:

Gewicht (GSM):

Fiber-Support-Index (FSI):

Abflussindex (DI):

Offener Bereich:

Stofffarbe:

Min Bestellmenge:

1 Stk

Preis:

inquiry

Verpackung Informationen:

Standardgehäuse aus Folienholz für die Ausfuhr

Lieferzeit:

5-8 Arbeitswochen

Zahlungsbedingungen:

L/C, D/A, D/P, T/T

Hervorheben:

Double layer paper forming fabric

Eight over sixteen shed weave fabric

High fiber retention drainage fabric

Beschreibung des Produkts

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Key Features

Eight over sixteen shed double layer weave construction
Fine mesh eight shed paper side with extra CD support yarns
Sixteen shed wear side weave for good service life
High fiber support for excellent retention performance

Product Parameters

Product Name	Forming Fabric PRINT DAL67816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..
